T-Mobile Revvl 5G vs Motorola Edge (2024) Specs Comparison

Availability

Officially announced
Aug 27, 2020	Jun 20, 2024
Prices (MSRP)
$400	$549

Design

Dimensions
6.51 x 3 x 0.37 inches 165.4 x 76.2 x 9.4 mm	6.28 x 2.83 x 0.32 inches (~0.44 inches with camera bump) 159.6 x 72 x 8.1 mm (~11.16 mm with camera bump)
Weight
7.58 oz / 215.0 g	6.14 oz / 174.0 g
Materials
Back: Plastic	Frame: Aluminum
Resistance
	Yes; IP68
Biometrics
2D Face unlock, Fingerprint (touch)	Optical in-screen fingerprint
Keys
Right: Volume control, Lock/Unlock key	Right: Volume control, Lock/Unlock key
Colors
Nebula black	Black

Display

Size
6.5-inch, 83.07% screen-to-body	6.6-inch, 90.92% screen-to-body
Type
	P-OLED, 144Hz, HDR, 1300 nits
Resolution
2340x1080px, 19.5:9 ratio, 395 PPI	2400x1080px, 20:9 ratio, 399 PPI

PhoneArena Display Test

Bright Max (20% APL)
Untested	Untested
Bright Min
Untested	2.7 (Average)

Learn more on our PhoneArena Display Test Results page.

Hardware

System chip
Snapdragon 765 SM7250-AA (7 nm)	Snapdragon 7s Gen 2 SM7435-AB (4 nm)
Processor
Octa-core 2400 MHz Kryo 475	Octa-core 4x2.4GHz Cortex-A78 4x1.95​GHz Cortex-A55
GPU
Adreno 620	Adreno 710
Memory
6GB (LPDDR4)/128GB	8GB/256GB (UFS 2.2)
Storage expansion
microSDXC up to 256 GB	not expandable
OS
Android (10)	Android (14)

PhoneArena Performance Test

GeekBench 6 Single
Untested	897
GeekBench 6 Multi
Untested	2758
3D Mark High
Untested	799
3D Mark Low
Untested	734

Learn more on our PhoneArena Performance Test Results page.

Battery

Type
4500 mAh	5000 mAh
Charging
	Fast charging Qi wireless charging
Charge speed
	Wired: 68.0W Wireless: 15.0W

PhoneArena Battery Tests

Battery Life Estimate

Untested

Browsing

Untested

Video

Untested

Gaming

Untested

Battery Life Estimate

7h 23min

Browsing

17h 41min

Video

10h 49min

Gaming

8h 57min

Learn more on our PhoneArena Battery Test Results page

Camera

Rear
Triple camera	Dual camera
Main camera
48 MP (PDAF)	50 MP (OIS, PDAF) Aperture size: F1.8 Sensor size: 1/1.5" Pixel size: 1.0 μm
Second camera
8 MP (Ultra-wide)	13 MP (Ultra-wide) Aperture size: F2.2 Pixel size: 1.12 μm
Third camera
5 MP (Macro)
Flash
LED	LED
Video recording
Yes	4K UHD
Front
16 MP Video capture: 1080p	32 MP

PhoneArena Camera Tests

N/A

Overall

N/A


N/A

Video

133

Overall

143


124

Video

Learn more on our PhoneArena Camera Test Results page

Connectivity & Features

Bluetooth
5.0	5.2
WLAN
a,b,g,n,ac Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac	a,b,g,n,ac,Wi-Fi 6,Wi-Fi 6E Wi-Fi Direct, Hotspot 802.11 a, b, g, n, ac, ax
USB
Type-C	Type-C, USB 3.1
Sensors
Accelerometer, Ambient light sensor, Proximity sensor	Accelerometer, Gyroscope, Compass, Ambient light sensor, Proximity sensor
Hearing aid compatible
M3/T4
Location
GPS, A-GPS, Cell ID, Wi-Fi positioning	GPS, A-GPS, Glonass, Galileo, BeiDou, Cell ID, Wi-Fi positioning
Other
NFC	NFC

Multimedia

Headphones
3.5mm jack	No 3.5mm jack
Speakers
Earpiece, Loudspeaker	Earpiece, Multiple speakers
Screen mirroring
Wireless screen share	Wireless screen share
Additional microphone(s)
Noise cancellation	Noise cancellation

Cellular

Carrier locked
Yes
5G Bands
n2, n25, n41, n66, n71, SA, NSA	n1, n2, n3, n5, n7, n12, n14, n20, n25, n29, n30, n38, n40, n41, n48, n66, n70, n71, n77, n78, SA, NSA
4G (FDD) Bands
1, 2, 3, 4, 7, 8, 12, 13, 20, 25, 26, 28, 66, 71	1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 20, 26, 28, 32, 66
4G (TDD) Bands
38, 39, 40, 41	38, 39, 40, 41, 42, 43
3G Bands
5, 8, 4, 2, 1	1, 2, 4, 5, 8
Data Speed
LTE, HSDPA+ (4G) 42.2 Mbit/s, HSUPA 5.76 Mbit/s, UMTS	LTE-A, HSDPA+ (4G) 42.2 Mbit/s
SIM type
Nano SIM	Nano SIM, eSIM

Regulatory Approval

FCC approval
Date approved: Jul 28, 2020 FCC ID value: 2ACCJN039
Measured SAR
Head: 1.34 W/kg Body: 0.87 W/kg Simultaneous Transmission: 1.54 W/kg Wireless Router: 1.12 W/kg Phablet: 3.95 W/kg
