Samsung SPH-A523
- Bookmark
- Posted: 21 Dec 2007
- Market Status: Released
-
Do you ...?
- US carrier availability: Virgin Mobile - Discontinued as Helio Mysto Helio - Discontinued as Helio Mysto
- Links: Samsung SPH-A523 manual Helio Mysto Official Page Helio Mysto Review
The Mysto is a slim slider, CDMA/EV-DO phone for Helio. It packs all typical for the carrier Internet features, 2-megapixel camera, QVGA display and GPS.
Rating
Samsung SPH-A523 specifications
also known as Helio Mysto
Pros
- Small dimensions (4.10 x 1.90 x 0.48 inches)
Cons
- Low resolution display (240 x 320 pixels)
- Low-resolution camera (2 megapixels)
- The camera lacks autofocus
- Lacks a standard (3.5mm) headphones jack
- Lacks an ambient light sensor for automatic screen brightness adjustment
Design
- Form factor:
Form factor - Refers to the form factor of a phone. The main handset designs are bar, clamshell, slide, swivel
- Slider
- Dimensions:
- 4.10 x 1.90 x 0.48 (104 x 48 x 12 mm)
- Weight:
- 3.35 oz (95 g)
the average is 4.2 oz (120 g)
- 3.35 oz (95 g)
Display
- Physical size:
- 2.22 inches
- Resolution:
- 240 x 320 pixels
- Pixel density:
Pixel density - The pixel density of a display represents the number of pixels over an area of one inch. It’s measured in “pixels per inch”, or ppi. The higher the number, the more detailed and good-looking the display is.
- 180 ppi
- Technology:
Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.
- TFT
- Colors:
Colors - Shows the number of colors that the display supports
- 262 144
Battery
- Talk time:
Talk time - Maximum talk time in hours
- 3.50 hours
the average is 8 h (497 min)
- 3.50 hours
- Stand-by time:
- 8.3 days (200 hours)
the average is 21 days (496 h)
- 8.3 days (200 hours)
- Capacity:
- 880 mAh
Hardware
- Built-in storage:
- 106 MB
- Storage expansion:
- Slot Type:
- microSD
- Slot Type:
Camera
- Camera:
- 2 megapixels
- Features:
- Digital zoom, Effects
- Camcorder:
- Yes
Internet browsing
- Browser:
- Yes
Technology
- CDMA:
CDMA - Code Division Multiple Access. A technique of multiplexing, also called spread spectrum, in which analog signals are converted into digital form for transmission. For each communication channel, the signals are encoded in a sequence known to the transmitter and the receiver for that channel. The foremost application is digital cellular phone technology from QUALCOMM that operates in the 800MHz band and 1.9GHz PCS band. CDMA phones are noted for their excellent call quality and long battery life.
- 800, 1900 MHz
- Data:
Data - Shows the particular phone's type of data. the major mobile phone data types are GPRS, CDMA2000 1xRTT, EDGE, CDMA2000 1xEV-DO, UMTS, etc.
- EV-DO
- Positioning:
Positioning - This field shows the positioning systems supported by the device. There are three main types: GPS, A-GPS and GLONASS. GPS - This is one of the most widespread global positioning technologies, developed and maintained by the U.S. government. It uses satellites in order to detect your location. Works best in clear weather. A-GPS - A-GPS stands for Assisted GPS and is the industry standard for positioning and navigation. “Assisted” means that it can use local wireless networks, in addition to satellites, for quicker and more precise localization. GLONASS - GLONASS is a global positioning system, developed by the Russian Federation. It’s very similar to GPS, but isn’t so popular in cell phones.
- GPS
Phone features
- Phonebook:
- 1000 entries, Caller groups, Multiple numbers per contact, Picture ID, Ring ID
- Organizer:
- Calendar, Alarm, To-Do, Calculator, Converter, Notes
- Messaging:
- SMS, MMS, Predictive text input
- E-mail:
- Yes
Connectivity
- Bluetooth:
- 2.0
- USB:
- Yes
Other features
- Notifications:
- Music ringtones (MP3), Vibration, Speakerphone
- Voice dialing, Voice commands, Voice recording
To see the full specifications with in-depth details click here.
Despite our efforts to provide full and correct Samsung SPH-A523 specifications, there is always a possibility of admitting a mistake. If you see any wrong or incomplete data, please LET US KNOW.
