HTC Nexus One CDMA

HTC Nexus One CDMA
Follow Following

More Photos (5)

The information for this phone is PRELIMINARY and could be incomplete or inaccurate. If you have any information about it, please send it to: phonearena@phonearena.com

Bookmark
Posted: 26 Oct 2009
Market Status: Canceled
Do you ...?
Want it1 Have it1 Had it0
Links: HTC Nexus One CDMA manual

The Nexus One is introduced by Google as the next step in Android evolution and the hardware found on is really impressive to say the least. As it was rumored, it packs a giant 3.7-inch AMOLED touchscreen with a resolution of 480x800 pixels. The handset is also featuring the Snapdragon chipset with a processor, clocked at 1GHz. It runs on the Android 2.1 operating system.

Rating

Not rated

Show Full Specs Compare

HTC Nexus One CDMA specifications

also known as HTC Passion

Design

Device type:
- Smart phone
OS:
OS - Phone that has capabilities, not usually associated with phones. Usually it has some of the above features: - Email, Web browsing - Personal information management - LAN connectivity etc
- Android (2.1)
Form factor:
Form factor - Refers to the form factor of a phone. The main handset designs are bar, clamshell, slide, swivel
- Candybar
Dimensions:
Dimensions - Phone's dimensions
- 4.69 x 2.35 x 0.45 (119 x 59.8 x 11.5 mm)
Weight:
Weight - Phone's weight
- 4.60 oz (130 g)
  the average is 4.4 oz (126 g)

Display

Physical size:
- 3.70 inches
Resolution:
Resolution - Refers to the width and the height of the display
- 480 x 800 pixels
Pixel density:
- 252 ppi
Technology:
Technology - Refers to the type of the color displays. There are five major types: LCD, TFT, TFD, STN and OLED
- AMOLED
Touchscreen:
- - Capacitive
Features:
- Light sensor, Proximity sensor

Battery

Capacity:
Capacity - Shows the battery capacity in mAh
- 1400 mAh

Hardware

Processor:
- Single core, 1000 MHz, Snapdragon
System memory:
- 512 MB RAM / 512 MB ROM
Storage expansion:
Storage expansion - Capability to add additional memory to your phone.
- Slot Type:
  Slot Type - Shows what type of additional memory can be added to the particular phone. Eight major memory slot types are available: MMC, SD, CF, Memory Stick Duo, miniSD, RS MMC, TransFlash (microSD), Memory Stick Pro Duo
  - microSD, microSDHC
- Maximum card size:
  Maximum card size - Shows the capacity of the memo0ry expansion slot that can be added
  - 32 GB

Camera

Camera:
Camera - Camera specs
- - 5 megapixels
- Flash:
  - LED
- Features:
  - Auto focus, Digital zoom, Geo tagging
Camcorder:
- - 720x480 (DVD) (20 fps)

Multimedia

Radio:
- - FM, Stereo, RDS
Speakers:
- Earpiece, Loudspeaker
YouTube player:
- Yes

Internet browsing

Browser:
Browser - Capability to access special Internet sites using the mobile phone
- - Yes
- Supports:
  - HTML

Technology

CDMA:
CDMA - Code Division Multiple Access. A technique of multiplexing, also called spread spectrum, in which analog signals are converted into digital form for transmission. For each communication channel, the signals are encoded in a sequence known to the transmitter and the receiver for that channel. The foremost application is digital cellular phone technology from QUALCOMM that operates in the 800MHz band and 1.9GHz PCS band. CDMA phones are noted for their excellent call quality and long battery life.
- 800, 1900 MHz
Data:
Data - Shows the particular phone's type of data. the major mobile phone data types are GPRS, CDMA2000 1xRTT, EDGE, CDMA2000 1xEV-DO, UMTS, etc.
- EV-DO Rev.A
Satellite system:
- A-GPS, Cell ID
Navigation:
- Yes

Phone features

Phonebook:
- Unlimited entries, Caller groups, Multiple numbers per contact, Search by both first and last name, Picture ID, Ring ID
Organizer:
- Calendar, Alarm, To-Do, Calculator, World clock, Notes
Messaging:
- SMS, MMS, Predictive text input
E-mail:
E-mail - Shows if the phone supports email features
- - Yes

Connectivity

Bluetooth:
Bluetooth - Low power radio technology replacing the need for wires connecting electronic devices such as personal computers, printers, palm top computers and mobile phones.
- - 2.1
Wi-Fi:
Wi-Fi - Wireless Local Area Network (WLAN) - used radio waves (RF) or infrared signals to send and receive data over the air. Most popular WLAN solutions today is Wi-Fi (802.11b and 802.11g) standards. 801.11b provides data speeds of around 11mbps while 802.11g can go up to 54 mbps.
- - 802.11 b, g, n
USB:
- - USB 2.0
- Connector:
  - microUSB
- Features:
  Features - Universal Serial Bus - is a plug-and-play interface for connection a computer and add-on devices such as joysticks, keyboards, wireless phones, scanner, cameras etc. USB supports hot-swap (ability to add a new device without having to reboot the computer). USB supports data speed of 12 megabits per second.
  - Mass storage device, USB charging
- Computer sync, OTA sync

Other features

Notifications:
- Music ringtones (MP3), Polyphonic ringtones, Vibration, Flight mode, Silent mode, Speakerphone
Additional microphone:
- - for Noise cancellation
Sensors:
- - Accelerometer, Compass
- Voice recording
