HP iPAQ rw6800

Jan 27, 2006
Market status


No pros


  • Slow data means slow Internet browsing (EDGE)
  • Lacks microSD slot for storage expansion
  • Single-core processor
  • Too little RAM memory (64 MB RAM)
  • It is so thick it needs a personal fitness trainer (0.77 inches inches)
  • Resistive touchscreen technology means its display is less sensitive than you would like it to be
  • Low resolution display (240 x 320 pixels)
  • Low-resolution camera (2 megapixels)
  • The camera lacks autofocus
  • Lacks an ambient light sensor for automatic screen brightness adjustment
  • Lacks a proximity sensor that turns the display оff during a phone call
  • No front-facing camera
  • Lacks global positioning system (GPS)




XDA Atom is compact Pocket PC Phone operating in tri-band GSM networks, featuring GPRS and EDGE. It operates on 416MHz processor and Windows Mobile 5.0 OS, featuring USB, IrDA, Bluetooth, and even Wi-Fi protocols. It has 2.0-megapixel camera with LED flash and QVGA color touch display and supports music playback through stereo speakers. Its memory is expanded through miniSD cards

Do you ...?



  • Device type:
    • Smart phone
  • OS:
    • Windows Mobile Professional (5.0)
  • Dimensions:
    • 4.02 x 2.28 x 0.77 inches (102 x 58 x 19.5 mm)
  • Weight:
    • 4.94 oz (140 g)
      the average is 5.2 oz (149 g)


  • Resolution:
    • 240 x 320 pixels
  • Technology:

    Technology - There are two main screen technologies currently used in phones and tablets: LCD and AMOLED. The former usually features a light source and liquid crystals, while the latter is based on organic light-emitting diodes. Newer LCD variations like IPS-LCD and Super-LCD allow for very accurate color reproduction and very wide viewing angles, where no significant image quality loss is observed. Current AMOLED screens differ in such a way that they can exhibit much more saturated colors (sometimes too much) and incredibly high contrast levels, which is due to black color being completely black in AMOLED displays.

    • TFT
  • Colors:
    • 262 144
  • Touchscreen:
      • Yes


  • Camera:
      • 2 megapixels
    • Flash:
      • Yes
    • Features:
      • CMOS image sensor, Mirror
  • Camcorder:
      • Yes


  • Processor:

    Processor - The processor is the main computing component of a phone and is a major factor when it comes to the overall speed of the device. Some more powerful smartphones use dual-core and quad-core processors designed to deliver greater performance.

    • Single core, 416 MHz, Intel PXA272
  • System memory:

    System memory - System memory, or RAM memory is the type of memory that the device uses to temporarily store data from the OS or currently-running apps. The more RAM available to the device, the better the performance will be when multiple or heavier programs are running.

    • 64 MB RAM / 128 MB ROM
  • Storage expansion:
    • miniSD


  • Talk time:
    • 5.50 hours
      the average is 15 h (872 min)
  • Stand-by time:
    • 11.7 days (280 hours)
      the average is 18 days (421 h)
  • Capacity:
    • 1530 mAh


  • Radio:
      • FM
  • Speakers:
    • Stereo speakers

Internet browsing

  • Browser:
      • Internet Explorer Mobile


  • GSM:
    • 900, 1800, 1900 MHz
  • Data:
    • EDGE
specifications continue after the ad


  • Bluetooth:
      • 1.2
  • Wi-Fi:
      • 802.11 b
  • USB:
      • Yes
    • Connector:
      • miniUSB
  • Other:
    • Computer sync, Infrared

Other features

  • Notifications:
    • Service lights, Music ringtones (MP3), Polyphonic ringtones (64 voices), Vibration, Phone profiles, Speakerphone
    • Voice commands, Voice recording

To see the full specifications with in-depth details click here.

This device is also known as O2 Xda Atom
