Leaked user manual for the Motorola DROID Bionic confirms 4.3 inch qHD screen

Posted: , by Alan F.

Tags:

Leaked user manual for the Motorola DROID Bionic confirms 4.3 inch qHD screen
As of last night, there were three major questions left pertaining to the Motorola DROID Bionic. What we didn't yet know about this eagerly awaited smartphone was the official launch date, the price of the phone and the size of the screen. But after FCC documents leaked the DROID Bionic's user manual, we can not only scratch that last question off the list, we can even add some new information about the phone.

According to the user manual, the Motorola DROID Bionic will be rolling out with a 4.3 inch qHD display, not the 4.5 inches that some had extrapolated from leaked photographs of the handset. Furthermore, the manual seems to indicate that the DROID Bionic will be a World Phone. There is a section of the manual that discusses World Phone GSM functions. This would make the device the first CDMA/LTE/GSM smartphone which could be quite stressful to the battery. As an LTE device, the DROID Bionic was going to need a SIM card anyway, so why not add that GSM radio for roaming?

Also discovered in the leaked material is the micro-HDMI port, right under the micro USB port. Now all we need is an official launch date from Verizon and the price. After we get that information, it will be just a matter of will power to keep that Verizon upgrade in your pocket until the Motorola DROID Bionic can be purchased at last.

source: FCC via AndroidCentralForums

The Motorola DROID Bionic user manual gives away the size of the display
The Motorola DROID Bionic user manual gives away the size of the display

The Motorola DROID Bionic user manual gives away the size of the display



**UPDATE**

Just adding a couple of more pictures from the FCC documents

Leaked user manual for the Motorola DROID Bionic confirms 4.3 inch qHD screen
